Product specification
Working size: 730mm*630mm Max 650mm*500mm min
Working efficiency: 3 sets of 6 laminates /min
Riveting thickness: 0.2-5mm
Prestack: CCD alignment, automatic prestack
Product features
Automatic plate thickness detection function to adjust the height of riveting, to achieve more accurate riveting effect
The number of rivets in each runner can be detected in real time by induction system to avoid missing rivet
Vacuum dedusting system can effectively remove impurities such as copper chips produced in the process of rivet blooming to ensure quality
The device is compact in structure and can be connected to other front and rear devices
